4G-10MDL

4G-10MDL

Log in for pricing

(No reviews yet) Write a Review
SKU:
G25615-0410
UPC:
710028545
Hose ID (in):
0.252
Term Dash Size:
10
C Cutoff (in):
0.858
L Length (in):
2.008
Trademark:
MegaCrimp Couplings
Hose Recommended:
Various ODs on Both 1-Wire & 2-Wire Braid Hyd Hose
Seal Type:
Mated Angle w/O-Ring
Seated Angle:
24
Swivel:
NO
End Size 1:
10
End Type 1:
MDL
Thread Size 1:
M16X1.5
Hose Dash Size:
4
Hose ID (mm):
6.4
The patented “C” insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented “C” insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert’s design ensures crimping forces are evenly distributed to form a concentric seal. The “C” insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose. Robust “bite-the-wire” crimp. Tested to an industry-leading 1 million impulse cycles. Environmentally-friendly TuffCoat™ plating for 347% better corrosion resistance SAE Standard. Popular thread styles also available with TuffCoat™ Xtreme™ plating for 583% better corrosion resistance than the SAE standard.
!
